SlurryPipeSystem v1.0.1.7

V1.0.1.7
Everything since V1.0.1.6. No config schema changes, savegames unaffected.
Fixed
Rear valve no longer opens with the pump on tankers using <turnedAnimation>

Reported on the Abbey tankers: with SPS installed, starting the pump swung the
rear valve open. Cause: the tanker XML keeps a vanilla
<turnOnVehicle><turnedAnimation name="..."/> — the base-game "valve opens
when the tanker is turned on" mechanic — and the SPS pump toggle drives
vanilla turn-on, so the same animation played on every pump start/stop.
SPS now disarms a <turnedAnimation> (or looping <turnedOnAnimation>) that
names an SPS-owned animation (spreaderValveAnimation / directionAnimation)
at registration, logged once — exactly as it already did for a movingTool
or <foldable> driving the same animation. Modders can leave the vanilla
line in place: without SPS it works as authored, with SPS the valve is
SPS-driven only.

Changed
Blocked outlets now say so on the spreader HUD

When an outlet section or the macerator is blocked, the panel adds a red
"Blocked — Clear at the outlet (pump off, valve closed)" row alongside
the red cells, so it's clear a blockage must be cleared on foot at the
outlet — refilling never clears it, and a joining player receives the
current blocked state from the server. Localised in all six languages.

Foreign-object clog chance lowered
The random clog chance on perfectly clean slurry (baseChance default) was
0.0015 per 6-second roll — about a 59 % chance of a clog per hour of
spreading, which read as random punishment. Default is now 0.0004
(≈5 % per load, ≈21 % per hour). Crust-driven blockages are unchanged; a
per-vehicle baseChance on <blockageNodes> still overrides the default.

BGA 250 config aligned with the release
The planET BGA 250 ships coupler-only (no SPS lagoon store), as in 1.0.1.6,
with the store opt-out made explicit in its config. No behaviour change
from 1.0.1.6.

Release V1.0.1.6
Everything since V1.0.1.5. No config schema changes, savegames unaffected.
Added
Spreader HUD can follow the help menu (F1)

New per-player setting under the SPS HUD section: Hide with help menu (F1).
Yes: the SPS HUD (dribble bar cells, pressure, pump readout) hides together
with the help menu when F1 is pressed, and returns with it. No (default): it
stays on screen exactly as before. Saved per player, never synced.

Changeover-lever animation — <pump directionAnimation=”…”>

Tankers can now show their vacuum/pressure changeover lever moving. Name an
animation from the vehicle’s own <animations> on the pump element
(<pump pumpType=”vacuum” directionAnimation=”myLeverAnim”/>); time 0 = FILL
(vacuum), time 1 = DISCHARGE (pressure). SPS plays the swing on every
direction toggle, snaps the pose on spawn and savegame load, and stays in
sync in multiplayer and on dedicated servers with no extra setup — the
animation rides the same direction event every peer already receives.

Coupler animations from the vehicle’s own <animations> block

Couplings can now reference vanilla animations by name —
connectorAnimationName=”…” / valveAnimationName=”…” on
<pipeCoupling> — instead of re-authoring the parts in <couplerAnimations>.
Start = disconnected/closed, end = connected/open. Save/load pose restore and
multiplayer sync work exactly like the id-based system; a missing animation
name warns in the log. Vehicle couplings only.

Rear-valve animation — <spreaderValveAnimation name=”…”>

Spreader tankers can animate their rear valve with the SPS spreader valve:
name an animation from the vehicle’s own <animations>; it plays open/closed
with the valve toggle (time 0 = closed, 1 = open), starts closed, and syncs
in multiplayer including late joiners. Sounds in the animation ride along.
A movingTool axis driving the same animation may stay in the XML for
players without SPS — SPS disarms it automatically at registration (logged),
so one XML serves both audiences. Same for the directionAnimation lever,
and for a <foldable> setup driving an SPS-owned animation: the fold key
then refuses with a clear warning instead of desyncing the lever.

Manual / hydraulic changeover as a store option

An outside direction control can declare store-configuration indices
(cabDirectionConfigIndex / cabDirectionConfigType) for which the
direction control moves into the cab — a tanker sold with a manual
changeover keeps the walk-up control, while the hydraulic-changeover
variant of the same tanker is switched from the seat (hydraulics
connected required). PTO at the node is unaffected.

Blockage clearing is now a proper job

The blockageAnimation no longer fires when a blockage happens — it now
belongs to the clearing: hold the clear key and the mechanism opens
(animation forward), the clearing time runs, and it closes back up
(animation reverse) before the blockage clears. Releasing early aborts and
winds it back. Without an authored animation, clearing is the plain timed
hold as before. Clearing now requires the pump off and the spreader valve
closed on every tanker type (vacuum tankers must also be vented), and other
players see the whole attempt in multiplayer.

Quieter, clearer logs

One line per vehicle names its nodeTree and how many nodes linked; a declared
but unloadable nodeTree, an unresolved blockage section band, and a missing
animation name each warn explicitly; the crust-vegetation load chatter moved
behind a debug channel. Silent failures keep getting louder, healthy loads
keep getting quieter.

Fixed
Coupler “connect” option lost when visuals are added under the mount node

The connect-detection arc group was found strictly as the mount node’s FIRST
child. A modder who nested coupler animation visuals (clamps, handles) under
the mount node before the arc group lost the connect option entirely — the
coupler still laid pipe, but walking a laid pipe’s end onto it offered
nothing. The arc group is now found by name (any direct child ending in
Arcs), with the old first-child rule as fallback, so child order no longer
matters. The coupler node structure is now documented in the tanker guide.

Open spreader valve: the pump only builds against slurry

With the rear spreader valve open, vacuum can no longer be built at all (the
valve must be closed to fill — no pumping-in while spreading), and pressure
builds only while slurry is aboard. An empty tank with the valve open builds
nothing and any stored charge vents at the fast rate.
New: the spread follows the gauge — spread rate and the size of the
discharge effect now scale continuously with stored pressure: no charge =
a slow gravity dribble with a small stream, half a charge = a visibly weaker
spread, full charge = the full-rate, full-size spread. Watch the stream fade
as the stored pressure tapers with the PTO off.

Working-speed cap released when the tank is empty

An open spreader valve kept the implement’s working-speed cap (and thickness
speed scaling) even with an empty tank — driving home empty at field speed.
The cap now releases as soon as there is nothing left to spread.

Blockage-risk HUD honours per-vehicle tuning

The risk row used the global crust thresholds, so a machine tuned to resist
blockages (e.g. a wide-bore splash plate with outletCrustMinRaw 0.85) showed
HIGH while its actual risk was near zero. Risk is now computed from the same
per-vehicle thresholds the blockage roll uses.

Store pipe effects during gravity / head-driven emptying

A placeable store’s own pipe effect only played while the connected tanker’s
pump was running with pressure built. A tanker emptying into the store by
gravity or head equalisation — pump off, level still falling — moved slurry
with no visible stream at the store inlet. The effect is now driven by the
same flow resolver that moves the liquid, matching the 1.0.1.4 fix the
tanker-arm effect got.

SPS nodes on a vehicle’s 2nd, 3rd, … component were invisible

Every vehicle-side node lookup searched only rootNode — which in FS25 is
component 1 and nothing else; the other components are its siblings, not
its children. Any SPS node authored on a later component (a coupler on the
sprung tank body so it rides the suspension, a fill arm on a rear frame) was
silently never found: nodeTree containers failed to link, and mountNodeName
lookups came up empty. Placeables never had this problem — their resolver
always searched every component; the vehicle side now does the same.
Affects the nodeTree container linker, all mountNodeName/surfaceRef/sound
node resolution, the whitespace-tolerant retries, the live-arm relink, and the
sprayer-side equivalents.
Both authoring styles remain fully supported, alone or mixed: SPS nodes
authored directly in your vehicle’s i3d (on any component — put them on the
component that physically carries them), and/or injected from a separate
<nodeTree> i3d shipped next to your vehicle. Nothing was removed; the log
now prints one line per vehicle naming the nodeTree and how many nodes it
linked, so you can see which path ran.

Release V1.0.1.5
Everything since V1.0.1.4. A small follow-up release: custom vehicle types that
descend from none of the vanilla tanker families now work, and the tanker /
fert-sprayer override families are kept cleanly apart. No config schema changes,
savegames unaffected.
Added
Custom vehicle types — the safety net

1.0.1.4 taught SPS to walk a type's parent chain, covering modder types derived
from the vanilla tanker or sprayer families. This release covers everything
else: a vehicle whose type descends from none of them (e.g. a modder's own
parent="sprayer" or parent="tractor" type, as in the LSFM Universal Tank
Pack) but that registers through an embedded <slurryPipeSystem> block now
receives the tanker behaviour per-vehicle at registration. The declaration
in the vehicle's own XML is the authority — the type family is just the fast
path. A log line names the type when this kicks in:
[SPS] custom vehicle type '...' is not in the tanker type family — N tanker override(s) applied per-vehicle at registration.
Fert/herb sprayers cannot be affected: only a pure slurry registration triggers
it, dual-registered sprayer/slurry machines keep their exact previous
behaviour, and blockage-only spreader implements (dribble bars) stay driven by
their tanker as before.

Fixed
Tanker / sprayer override families kept apart

With 1.0.1.4's parent-chain walking, the vanilla tanker types (which themselves
descend from the sprayer types) also collected the fert-sprayer override set a
second time on top of the tanker set. Harmless in play (the functions
self-guard), but the two families are now resolved exclusively — a type is
covered as a tanker or as a sprayer, never both.

v1.0.1.2:

Added
Front-mount fill arm system (Claas Saddle Trac pack)
    Front-mount pass-through pump — a capacity-0 front unit (HVP) that fills a
    hose-connected receiver tanker. Works on any tractor, not just the Xerion: SPS injects
    Giants connection hoses (plain-type TOOL_CONNECTOR_TOP_RIGHT) into the vehicles' own
    hose systems at registration time, so vanilla treats them as native hoses. The Xerion's
    own specType hose circuit is detected and left alone — no duplicate hoses.
    Pass-through pump cascade — the front mount resolves two tank-side outlets in strict
    priority every tick: connected pipe couplings with the valve open first, then the
    hose-bridged rear receiver. Filling sends liquid to the first target with free capacity;
    unloading draws from the first with content — so a coupler tanker fills first, overflow
    goes to the rear tanker, and it switches back automatically as levels change. Full mirror
    for unloading. Water is a valid infinite fill source and refused as an unload destination.
    New config schema — <frontMount><hose> on the front unit;
    <tractorMountFillArms accepted="true"><hose> + <staticPipe> on receiver tankers;
    config-gated hoses and static pipes via cylinderedConfigIndex; objectChange
    visibility on connect/disconnect transitions with optional initialState="inactive".
    Standard receiver mount node name: slurryPipe.

Front / rear tank combos ("FlowControl")

    Any front tank pairs automatically with any rear sprayer on the same tractor sharing a
    fill type — no per-pair config, no keybind, only the pipe-connected vehicle needs an SPS
    block. One connection fills both (split proportional to free capacity — both reach
    full together) and drains both (proportional to level — empty only when both are).
    Automatic balancer modelled on the real Amazone FT-P: rear held at 30% from the front
    tank at 200 l/min, topped up to 40%, so the front always empties first and front axle
    load is preserved. Optional tuning via
    <frontTankBalance lowPct highPct transferLitersPerMinute/>.

Sprayer buying station

    Placeables can now sell liquid fertiliser / herbicide straight into the sprayer pipe
    system. A part-full sprayer auto-switches the station to its held liquid on connect and
    locks the type switch while connected. WATER is always refused from the sprayer cycle.
    Slurry and sprayer buying stations are mutually exclusive on one placeable (warned in
    the log). <extraFillTypeCategory> lets script mods add their own liquid categories
    (e.g. Soil & Fertilizer). Shift + activate reverses the type-switch cycle on both slurry
    and sprayer stations.

Store info box — per-tank rows

    Standing at a fertiliser store now shows one row per physical tank — T-1, T-2, … — with
    each tank's held liquid and litres, matching the N-couplers = N-liquids rule.

New vehicle support

    Rau Spridoport rear sprayer + Rau front tanks (Xylon and GTA) from the Fendt
    FarmCon pack — working FlowControl combos out of the box.
    PlanET BGA Modular (community contribution — thanks dev-mich, PR #23): Guelle
    and Gaerreste stores wired into SPS via config injection, with per-coupler fill types
    (LIQUIDMANURE / DIGESTATE).
    Vervaet Hydro Trike XL (selfPropelledManureBarrel) now fully supported — see Fixed.

Compatibility & safeguards

    Drive-input watchdog — some mod combinations (seen with Courseplay) could leave a
    vehicle unable to drive after selecting implements. SPS now monitors the drive axes once
    a second, logs a full diagnostic scoreboard when the broken state persists, and
    self-heals the action bindings (up to 3 attempts per vehicle entry).
    New vehicleRole="slurry|fertiliser" vehicle attribute for edge cases where vanilla's
    sprayer classification gets a machine wrong.
    New debug channel SPSM_Sprayers.FrontTank ([SPS FT-BAL] combo/balancer trace).
    All channels still ship off.

Translations

    sps_infoTankEmpty ("Empty") and warning_spsSlurryThickeningWater added to all five
    languages (EN / DE / FR / IT / NL).

Fixed

    Slurry stores could jam permanently and water dilution did nothing. The
    liquid-first draw bias was applied unconditionally and the maths meant dry matter was
    never removed at all — pumping thinned nothing and added water came straight back out.
    Now: solids leave with every draw in honest proportion; the concentrating draw only
    applies to settled stores (a fresh or fully mixed store drains completely to zero, so
    mixing before pumping has a real purpose); an empty-store dead band stops "add water"
    advice appearing on empty stores; and existing savegames with inflated solids values are
    repaired automatically on first load (logged per store).
    Thickness warnings now name the actual remedy — four distinct states (thickening,
    thickening + add water, needs mixing, too thick) instead of always advising mixing.
    DE/FR/IT "too thick" strings corrected (they wrongly advised agitation for a state where
    agitation cannot help). Conduit HUD fixed: thickness percentage always read 0%, and the
    needs-mixing state had no display branch.
    Vervaet Hydro Trike XL showed no pump gauge. Vanilla misclassified it as a
    fertiliser sprayer because its sprayer spec pointed at the diesel tank; SPS now uses its
    own registration to decide the exemption (all five gate sites), the config's
    fillUnitIndex was corrected, and the tanker override gate covers
    selfPropelledManureBarrel.
    Pipe effects no longer require a smoke node — every effect gate now needs only the
    main effect node; the smoke layer is built only when a smoke node exists.
    Spreader valve keybind no longer appears on front-mount units (they are
    manureBarrel-typed but have no spreader).
    Equalisation no longer fights the front-mount pump (neutral gate while the front
    pump is driving a transfer).
    Dynamic store per-tank rows went stale after buying at the store's own trigger —
    totals updated but T-rows didn't until the next pipe session. A one-second server-side
    reconcile now credits external fills within a second, SP and dedicated servers alike.
    "Missing 'sps_infoTankEmpty'" shown on empty tank rows — entry now shipped in every
    language.

Changed

    Documentation: main README feature list updated (front mounts, FlowControl combos);
    Fert/Herbicide Sprayer guide gains §12 (front/rear combos, pairing rules, balancer
    tuning, debug channel); Placeables guide §4 now documents the pipeCoupling#fillType
    restriction attribute (was parser-supported but undocumented — thanks dev-mich for the
    catch).
    Multiplayer audit completed against vanilla network sources: all 29 SPS event classes
    verified structurally correct, server-authoritative fill mutations confirmed, and
    join-in-progress state dump coverage verified.

Removed

    Nothing.

Known limitations

    A buying-station fill lands in the connected vehicle's own tank only; with a front/rear
    combo attached, the balancer redistributes rearward automatically afterwards.
    Agrio Gigant and Agrio Mamut XL manifest entries are prepared but commented out pending
    the mods' vehicle files.

Covers 25–31 July 2026 · V1.0.0.10 → 1.0.1.1
Each entry states what was wrong, why it was wrong, and what changed. Line references are
against the V1.0.1.1 tag unless noted.

Version 1.0.0.10
New features
Slurry separator (Börger 125 bunker separator) — new screw-press placeable
(manureHeapSeparator type): pulls slurry in through one coupler, presses the dry matter
onto its own manure bunker, returns the thinner liquid fraction through the other coupler.
Walk-up start/stop and 5-step screw tightness control; auto-halts on exhausted dry matter
or a full bunker and resumes on its own; optional running cost per hour. Fully
server-authoritative, MP-synced, join-in-progress safe, saved per game. Third-party
placeables can configure their own machine via <slurryPipeSystem><separator>.
Buying station support — FS25_BuyableManureAndOther's liquid manure station registers
as a paid, infinite pipe-only SPS source with a walk-up switch between its sold liquids
(plus SPS-extra types such as water). Charges through the station's own pricing; MP-synced
and JIP-safe.
Gravity head equalisation — new optional headHeightNodeName on vehicle and store
couplings. Levels equalise by gravity between connected vessels, gated on the pipe run's
declared high point, so slurry only flows downhill when it genuinely can. Couplings
without the attribute behave exactly as before.
Lid-linked deployable couplers — new deployAnimatedObjectSaveId on store couplings
drives the placeable's own vanilla animatedObjects lid: deploy opens it, connecting
requires it fully open, and the lid's walk-up trigger locks while a pipe is live. Shared
lids across several couplers supported via one shared animated object.
Sprayer store fill-type control — placeable sprayer couplings can now declare their
own fill type and capacity (#fillType + #capacity), or act as dynamic
lock-until-empty compartments (#fillTypes / #fillTypeCategories, including
fillTypes="ANY" which accepts whatever the connected sprayer holds — script-mod
liquids included). Compartment state saves, syncs in MP and survives JIP.
Per-config coupler animations — vehicles and placeables (slurry and sprayer) can ship
their own <couplerAnimations> block inside the embedded config; local ids override the
shared library.
Pipes rest on real surfaces — laid chains and connection pipes now settle onto
concrete pads, building floors, bridge decks and roads (per-bone raycast), not just the
terrain, across all three pipe visual systems.
Soil & Fertilizer compatibility — all 12 FS25_SoilFertilizer custom liquid IBC tanks
are recognised; SPS spawns the correctly branded IBC for the connected sprayer's liquid.
IBC spawn control — optional IBCspawnPoint child node on a sprayer coupler dictates
the hold-R spawned IBC's position and heading; the Add IBC prompt is suppressed while the
sprayer is empty.
Embedded crust visuals — the <crust> foliage/plane block now works on placeables
registered via the embedded <slurryPipeSystem> block (previously bundled-config only).
Per-player settings — the pipe colour picker and the entire spreader HUD section have
moved to the General settings page, so every player in multiplayer (not just the
host/admin) can use them. Each player's choices — including the dragged HUD position and
scale — now persist in their own local user file across sessions and servers.
Multiplayer gameplay settings sync — the gameplay rows (Slurry Realism, Thickness
Flow, Blockages, Length Falloff, Shear Bolt, IBC Persistence) are now server-
authoritative: admin changes apply on the server, broadcast to every client, and reach
late joiners in the join dump. The shear bolt master switch now actually disables bolt
wear (it was previously unconnected).

Fixes
valveType="NONE" store couplers no longer show a phantom "Open valve" prompt anywhere on
the run — walk-up interaction is connect/disconnect only, and the far end is treated as
free-flowing.
Savegame reload no longer duplicates or loops back coupler bez pipes; a load-side
sanitizer heals already-corrupted saves.
Multi-type husbandry storages (straw + slurry) no longer risk draining STRAW or converting
deposits into the wrong type — transfers are gated on a pumpable-liquid allowlist.
Digestate deposited into a slurry-holding tank now merges into the held content instead of
creating a separate pool.
Pressure direction fix: a tank charged to vacuum can no longer discharge at full rate when
flipped to pressure (sign-aware flow scalar), with a vacuum-seal gravity guard and
dead-band equalisation through the pressure transit window.
Coupler animations no longer fail for players whose session registration order latched an
empty animation library — the library resolves regardless of load order.
Chain terminus bonds to stores and free-standing termini now persist across savegames.
Slurry tank extension flags are cleared on LIQUIDMANURE/DIGESTATE storages so extensions
behave as independent SPS stores.
Pipes no longer bounce or launch into the air while being laid (self-collision feedback
removed by stripping floor collision bits at load).
Laying new pipes near existing connected chains works again (in-service anchored termini
and mid-chain joints excluded as connect candidates).
Separator solids no longer vanish in sub-litre pushes; the manure heap fills correctly,
and store settle/crust scales down as dry matter is withdrawn.
Release log hygiene: the separator debug channel no longer ships enabled; previously
ungated multiplayer receive prints (chain state/request/connect, docking station, chain
lock) and the sprayer cab action-strip prints are now behind debug flags.
Localisation: German, French, Italian and Dutch brought to full English parity — 15
missing separator and buying-station entries added, and 3 previously untranslated
agitator PTO strings translated.

Version 1.0.0.8
Fixed issues with multiplayer, pipes and valves plus sync problems
Few other tweaks

Version 1.0.0.5
Changes made for bug fixes and updates.

A realistic slurry pipeline system for Farming Simulator 25.
The FS25 Slurry Pipe System (SPS) replaces the simplified vanilla mechanics of the game—simply drive up to a trigger and fill—with a fully interactive pipeline system.
Physically connect filling arms or pipes, operate a PTO-driven pump, build up pressure, control the flow direction, and watch the slurry actually move through a connected pipeline system.
The slurry itself behaves realistically: it becomes more viscous over time, forms crusts if not regularly stirred, and can clog pipes or distributors if neglected.
